BTF-80
Axial Ex Metal Blower
Udyogi Ventinout® is designed for applications requiring larger amounts of air output.
| Diameter | 32"" (800 mm) |
| Type | Explosion Proof |
| Style | Axial Fan |
| Motor | 4.0 HP |
| Voltage | 240 V |
| Frequency | 50 Hz. |
| Speed | 960 RPM |
| Free Air Capacity | 14832 CFM (420 m3/min) |
| Weight | 89 kg |
| Dimensions | 111 (L) x 101 (W) x 64 (H) cm |
| Color | Yellow |
- Dynamically designed fan housing to optimizes airflow efficiency.
- Protective guards meeting OSHA standards.
- Impeller is designed for high Static pressure providing higher airflow rate.
- Equipped with four heavy duty locking caster wheels for easy transport .
- Adjustable angle for easy setup.
