90 Kv Rescue Stick
The TP1290 Kv Rescue Stick is engineered to handle the demanding requirements of emergency response in high-voltage settings. Built specifically for rescuing technicians and workers from electrical accidents, it is ideal for category 1, 2, and 3 substations. This tool can quickly and safely help bring an injured or electrocuted person back to a secure area, minimizing risks to the rescuer.
| Model No | TP1290 |
| Operating Voltage | 90 kV |
| Test Voltage | 100 kV |
| Overall Length with Hook | 2.29 m (7.5 ft) |
| Overall Length w/o Hoo | 1.97 m (6.46 ft) |
| Weight | 1.7 kg |
| Opening of the Protected Area (Hook) | 600 mm (23.62 inch) |
| Hook | Steel Tube 18 x 1.5 cm |
| Hook delivered | Dismantled |
| Color | Yellow |
- Stick for rescuing an injured technician (electrocution, dizziness...), working on category 1, 2 and 3 substations.
- It is used to grasp the injured person by the waist and bringhim back to a protected area.
- The hook is fully non-conductive, making it safe to use around electrical equipment and wires.
- The Safety Rescue Hook is a durable and strong tool that is perfect for use in emergency situations.
- Rescue Stick are insulated for use with MV-HV voltages up to 90kV.
