6220 SS Combination Eye/Face Wash and Safety Showers
- Home
- /
- Emergency Shower & Eyewash
- /
- Combination Eye/Face Wash and Safety Showers
- /
- SS
- /
- 6220 SS Combination Eye/Face Wash and Safety Showers
6220 SS
A combination of Safety Shower & Eyewash, operated independently by push lever & pull rod
| Material | SS 304 Material |
| Operating Pressure | 2-3 Kg/cm² |
| Water Flow | Shower: 76 LPM & Eyewash: 12 LPM |
| Construction | 304 Stainless Steel |
| Available In | 316 Stainless Steel |
- Water inlet connections of 1-¼” NB.
- Water outlet connection – 1¼” NB.
- Head shower discharge rate – 76 lpm (minimum).
- Eye wash discharge rate – 12 lpm (minimum).
- Push plate for one hand operation.
- Push to open valve - connects unit to uninterruptible water supply.
- Base plate - to hold the shower structure in a stable position (Size-180 mm).
- Newly introduced straight model body for better flow of water in minimum time.
- Welded base flange and drain outlet introduced for easy installation.
- Square base flange for better positioning on ground surface.
- External 1-1/4” BSP thread of drain outlet introduced.
